Typical Problems Encounted During Ex i Inspection
Published
Read Time: 5 mins
Throughout any inspection campaign non-compliant issues are going to be found. Here are some common issues we have found whilst conducting inspections on Intrinsically Safe equipment
- Incorrect Zone (Zones 1 and 2 for Ex ib; Zones 0, 1 and 2 for Ex ia)
- Incorrect Group for hazardous area classification Incorrect
- Temperature Classification for hazardous area classification
- Incorrect ambient temperature range for environment
- Documentation missing or incorrect
- Certificate of Conformity not read
- Labels missing or not illegible
- No separation of IS and Non-IS circuits
- Entity calculations not checked correctly or incorrect values used
- Barriers swapped out and IS calculations not re-checked
- No dedicated IS earth/bar
- Earthing missing from Galvanic / Zener barriers
- Uncertified or incorrectly certified barriers installed in the hazardous area and no Conformity Assessment Document
- Screens not earthed at one end (preferable in the Non hazardous area) and not secured in terminals in the hazardous area
What others can you think of?
