Fitness for Purpose Study – Changes to Unit Verified Ex e Enclosure

Published 13 Jul '20
Read Time: 5 mins

AS/NZS 60079.17:2017 Annex C provides guidance on conducting a Fitness for Purpose Assessment. This is an “informative” Annex and is not necessarily mandatory. However, using this guidance will provide an assessment of compliance with no “holes” in it.

An Ex e enclosure fitness for purpose report should:

• Be undertaken where the original enclosure:
• has IECEx or ANZEx Certification but is empty or
• may have Unit Verification (under IECEx) for a specific list installed, certified, internal equipment, but the items installed have been changed outside of certification.
• Demonstrate the equipment is “fit for its purpose” and “safe to use”, with conditions of use as required.
• Be a form of risk assessment which demonstrates an equivalent level of safety to a similar product which has been certified, considering all potential eventualities. Some examples are:
• Surface Temperature and Temperature Classification – assuming internal components have been changed.
• The use of other certified apparatus in conjunction with the parent equipment, as an entire assembly.
• Creepage and Clearance distances maintained.
• Certification of components used in the original complete assembly – conformity assessments as required for the individual components.
• Demonstrate compliance to AS/NZS standards.
• Consider any likely ignition sources and their probable frequency.
• Define the purpose and use of the equipment, including the hazardous area in which it is to operate and relevant environmental conditions.
• Limit the use of the equipment to a particular site or usage for one entity.

Compliance to AS/NZS standards including installation and inspection standards, must be demonstrated. In order for a Fitness for Purpose report to “hang together”, it needs to have evidence for all claims, or acceptable calculations or analysis for any statements or assumptions made.

Case of Modified Unit Verified Ex e Enclosure

Example:

Scenario:

 Assessment:

• Initial: The Zener Barrier will dissipate only a few watts. The enclosure has a mass of some 15 kg, measures 30 x 30 x 30 cm and is 25 mm thick and is made of a cast light alloy.
• Assume that the enclosure is in direct sunlight (in the Pilbara are, W.A.) and that insolation (the absorbing of solar heat) will give rise to a 60°C surface temperature – which can be taken as the Ambient Temperature in this instance, with no internal power dissipations considered.
• Refer to the Zener Barrier certification and use the following calculation – P_max = 2 x U_o x I_o (2 times for maximum power transfer). Assume U_o = 28V and I_o = 100 mA. P_max is then calculated to be 5.6 W.
• Calculations based on the enclosure geometry can be made (available from many on-line resources or enclosure handbooks) to determine what power dissipation will achieve what surface temperature rise.
• Confirm compliance to T6 requirements as follows:
• Assuming T6 compliance for the moment, this is limited to an 85°C surface temperature in a 40°C ambient. That is – a 40°C Temperature Rise. Note that 40°C is the reference temperature at which all temperature classifications are defined – an assumption allowed unless another ambient temperature has been specified under certification.
• Using a 5°C factor of safety, assume an 80°C maximum surface temperature for a 40°C ambient temperature.
• This is a 40°C temperature rise over the 40°C ambient temperature. However, as the actual assumed worst case ambient temperature is 60°C, the maximum temperature rise that is allowable (with the 5°C factor of safety is 60°C - 40°C = 20°C.
• Calculate the power dissipation required for a 20°C temperature rise in a 60°C ambient temperature for this enclosure geometry. Calculated elsewhere – this is approximately 160W maximum for T6. See https://www.oemheaters.com/topic/enclosure-heating - one of many resources on line.
• It has been calculated that the maximum internal power dissipation cannot exceed 5.6W by limitations of the Zener Barrier design.
• Therefore, with only the Zener Barrier installed, a Temperature Classification of T6 can be awarded for a 60°C ambient temperature.
• Consider other aspects of the design, such as the likelihood of Pressure Piling within the enclosure (in this case, with a sole Zener Barrier installed – and not crammed with other components – this would be unlikely).
• Also confirm that the IP ratings of all the components (glands) are no less than that of the enclosure.
• Allocate a marking code for the enclosure (considering it has no temperature classification marked on it and considering this now has an intrinsically safe output). In this case Ex d [ia] IIB T6 IP66 (Tamb ≤ 60°C).
• Affix a label to the enclosure modelled on the example from the standard:
• Compile the report based on recommendations on AS/NZS 60079.17 Annex C.
• Make the statement at the end of the report that the enclosure with the Zener barrier installed (quote model numbers and certificate numbers) is considered to be “Fit for Purpose” as currently configured and that any changes to the contents of the enclosure will nullify this assessment, and will require reassessment.
