HF Micro RFID Tag

$908.60 AUD
Approx $587.86 USD

Choose Type & Qty:

We accept Mastercard and Visa. All goods are shipped via Australia Post

The Micro RFID Tag features three semiconductor options:

Mifare Ultralight
Mifare 1K
ICODE SLIX-L

The HF Micro Tag has achieved certification for Group I, II & III, ensuring comprehensive coverage for all your application needs. Elevate your Mining and Oil & Gas operations with the reliability and adaptability of this RFID Tag – where innovation meets safety

This is a miniature off-metal tag that delivers unparalleled performance for its compact size. It opens up new possibilities for businesses to enhance their asset management, especially for computers and other devices containing valuable data.

Electrical Specifications:

Air Interface Protocol: ISO / IEC 15693
Operational Frequency: 13.56 MHz
Chip: I-CODE SLIX-L, Mifare Ultralight, Mifare 1K
Product Code: H342209 / H34158 / H342098
Read Range: Up to 50 mm
Write Endurance: 10,000 cycles
Data Retention: 50 years
Ingress Protection Rating: IP67
Attachment: Riveting/Screw/Adhesive
Applicable Surface: Plastic/Wooden

Physical and Mechanical Specification:

Dimensions: 52 ± 0.3 x 16 ± 0.2 x 8.5 ± 0.2 mm
Hole Diameter: Ø 3.0 mm
Weight: 8 g
Encasement: Polypropylene and Polycarbonate
Color: Grey
Quality Assurance: 100% reader tested

Chemical Resistance:

Resistant to continuous exposure to salt water for 2 hours
Resistant to continuous exposure to motor oil for 2 hours
Additionally, abrasion resistant against HCL and IPA

Certificates and Markings:

IECEx TSA 21.0010X

Temperature Range:

-20°C to 70°C

Additional Services:

Pre-encoding available on request
