HF Cylinder Tag

HF Cylinder Tag

The cylinder tag RFID features two semiconductor options:

• ICODE SLIX-L
• SIC 5600

Discover the cylinder tag, an advanced RFID Tag tailored for precision and resilience this tag ensures longevity and robust performance.

The cylinder tag  RFID has achieved certification for Group I, II & III, ensuring comprehensive coverage for all your application needs. Elevate your Mining and  Oil & Gas operations with the reliability and adaptability of this RFID Tag – where innovation meets safe.

Electrical Specifications:

• Air Interface Protocol: ISO / IEC 15693
• Operational Frequency: 13.56 MHz
• Expected Lifetime: Up to 10 years in normal conditions
• Ingress Protection Rating: IP66
• Read Range: Up to 35 mm
• Chip Options: ICODE SLIX-L, SIC 5600

Physical and Mechanical Specification:

• Product Name: Cylinder Tag
• Dimensions: 38 x 28 x 4 mm
• Product Code: H311209 / H311231

• Weight: 20 g
• Encasement: Polypropylene and Polycarbonate
• Hole Diameter: Ø 9.6 mm
• Quality Assurance: 100% reader tested
• Colour Options: Any colour can be used

Chemical Resistance:

• Resistant to continuous exposure to salt water and motor oil for 2 hours
• Additionally, abrasion-resistant against HCL and IPA

Additional Services:

• Pre-encoding available on request

Certificates & Markings

• IECEx TSA 21.0010X
          Ex ia Ma
          Ex ia IIC T6 Ga
          Ex ia IIIC T135°C Da

Temperature Range:

• -20°C to 70°C

Brochure Download

Click to download

Certification  Download

Click to download

PRICING FOR BULK BUYS

Generous discounts apply for bulk orders for 1,000 or more tags. Contact us online for bulk order enquiries.
